DM3 Vertical Bend 45 Degrees

Elevate your conveyor system with the DM3 Vertical Bend 45 Degrees, engineered for efficient vertical maneuverability.

• Tolerance: ± 2 degrees & Radius: ± 10mm.
• Connecting strip and M8 hex screw included.

Variants:

• DM3 Vertical Bend 45 Degrees, R400
  • Effective track length: 0.47m 1-way (0.94m 2-way).
  • Weight: 1.8kg
  • Supply: 1 Unit

• DM3 Vertical Bend 45 Degrees, R1000
  • Effective track length: 0.95m 1-way (1.90m 2-way).
  • Weight: 3.5kg
  • Supply: 1 Unit
